Aluminum Fin
Architectural aluminum fin systems offer a versatile, cost-effective solution for creating striking decorative façades, delivering the modern look of custom decorative fin walls and parametric aluminum fin systems. These lightweight, durable fins also function as pre-engineered sunshade fins and curtain wall fin systems, enhancing energy efficiency through effective solar shading with aluminum sun control blades. Easy to install and adaptable to a variety of building designs, they provide developers, construction professionals, and architects with a streamlined, cost-effective option. Success Build Systems customizes each project to align with your vision, ensuring seamless integration and a refined final look available across the USA now and soon globally.
CONNECTION DETAILS
REGULAR (SHORTER) CONNECTION
All profiles except the ones above the main entrance will be connected with a regular type of connection. These profiles have a 2’’-4’’ section, and will be mounted with the 2’’ edge facing forward, and will be installed 4’’ apart from each other. There are 245 pieces (32’ 2’’ length) of this type of profile.
EXTENDED CONNECTION
Profiles above the main enterance will be connected with extended type of connection. These profiles have 2’’-6’’ section, and will be mounted with the 2’’ edge facing forward, and be installed 4’’ apart from each other. There are 37 (73’ 6’’ length) pieces of this type of profiles.
There will be two anchorage knot in each this type of profiles.
One is on the top, and the other one is on the bottom line of the profile. Also there is one-meter steel profile where the two profiles are connected vertically for strengthening. If it is considered necessary statically, a third one can be added on 34’-2’’.
